The Raven Three is an ergonomic LED panel made from cast aluminum and lightweight durable plastic modules. Its cabinet design simplifies maintenance, allowing for easy rear access thanks to a fully magnetic structure and clip-type module handles. This ensures efficient and reliable installation. Designed for indoor and outdoor use, the Raven Three boasts an IP65 rating for water and dust resistance and anti-corrosion properties thanks to its durable cast aluminum and plastic construction.

High refresh rate


Quick locking system


Wide aspect horizontal
mounting


With a 3840 Hz refresh rate, the module delivers clear and stable visuals with fluid motion, ensuring great performance for dynamic and fast-moving content.

It permits a fast and secure installation, ensuring the panels are easily attached and removed.

This feature allows a distinctive horizontal installation, offering greater versatility than most LED panels.


IP Rated


Pro production panel


14 bit

The Raven Three has an IP65 protection rate, which means it is fully protected against rain and dust, ensuring reliable indoor and outdoor performance.

This panel is designed for versatility and is ideal for various pro production applications, including concerts, tours, stadiums, and more.

Featuring a 14-bit high grayscale processing capability, the Raven Three offers superior color accuracy and smooth gradation without losing any information.

GALLERY

Screenshot 2025-01-13 at 12.17.45 p.m..png
Screenshot 2025-01-13 at 12.06.56 p.m..png
Screenshot 2025-01-13 at 12.08.24 p.m..png
Screenshot 2025-01-13 at 12.16.56 p.m..png

PRODUCT SPECIFICATIONS

Physical Specifications

:

IP Rating
Pixel Pitch:
LED Type:
Module Resolution (Pixels):
Module Size (mm):
Panel Resolution:
Pixel Density (Per Panel):
Power Connection:
Panel Material:

IP65
3.9
SMD 1921
128 X 64
500mm X 250mm
256W x 128H
32,768
Panel Mount Seetronic In/Out

Cast Aluminum

Optical Specifications

:

Brightness:
Optimal Viewing Angle Horizontal:
Optimal Viewing Angle Vertical:
Scan Method:
Refresh Rate (Hz):


4,000nits
140°
140°
1/16s
3840



Electrical Specifications

:

:

Module Size:
Panel Size:


Panel Weight:




30 Panels
Rear accessible

4,000nits
140°
140°
1/16s
3840

Input Voltage:
Power Consumption:
Maximum Power Input (W/m^2):
Average Power Input:
Power Link at 110V
Power Link at 220V

110-240VAC 50/60Hz
193W / 1.64amp @110
400
200
8
20


Installation Specifications

Dimensions

:

:

Vertical Rigging Quantity (pcs) with appropriate
hardware:
Service:

500mm X 250mm
1000mm (Length)
63mm (Wide)
500mm (Height)
25lb (11.34kg)



PRODUCT DETAILS

Data Sheet.png
Data sheet EN
Accessories
Manual EN
